DC New

Basic Info.

Model NO.	DCSP240020
Power Source	Half-Bridge Type
Connection	Plug In
Brand	Freeman
Output Protection	Over Hot Protection, Short Circuit Protection
Working Temperature Range	0~25 Degree
Output Protection Function	Over Voltage Protection, Over Current Protection
Certificates	CE, GS, UL, cUL, SAA, CB, Inmetro
Accord Standard	UL60950-1, En62368-1
Storage Temperature Range	10~70 Degree
Insulation	3kv/5mA
Efficiency Level	VI
Ripple Wave	1%
Input	100-240VAC
Aging Test	100% Aging Test
Transport Package	Carton + Pallet
Specification	55.00cm * 35.00cm * 22.00cm
Trademark	freeman
Origin	Ningbo
HS Code	8504401400
Production Capacity	1000000 Pieces/Month

Product Description

Model NO.	DCSP240020	Ripple Wave	1%
Input	100-240VAC 50/60 Hz	Insulation	3KV/5mA
Output	24VDC 200mA	Approval	UL CUL GS CE CCC UKCA PSE KC CB RoHS
Protection	OTP OVP OCP STP	DC Cable	1.2m/1.5m/1.8m(Customized Available)
Voltage Tolerance	±5%	Warranty	3 Years

Electrical
Topology: Swicthing FlybackDielectric Withstand: 3000VAC Primary - SecondaryLeakage Current:0.25mAEfficiency: CoC ErP CertifiedMTBF: 100,000 Calculated Hours at 25ºC,by Telcordia SR-332
Environmental
Operating Temperature: 0 to +40ºCStorage Temperature:-20 to +70ºCRelative Humidity:Operating:20 to 80% RH,Storage:10 to 90% RHCooling:Natural Convection Cooling

Ningbo Freeman Technology Co.,Ltd was a group that located in Ningbo City which own that largest Ningbo port all over the world,also close to Shanghai port. Shanghai international airport and Hangzhou internation airport. The transport is very convenient to visit and ship goods to anywhere in the world.
We are a one stop power solution supplier that specialized in switching power supply, pure sine wave incerter,control PCB board,isolated power transformer, photoelectric encoder,wireless bridge and etc. Our products are widly used in communication, medical device,electronics,LED lighting,audio,new energy,instrumentation,home appliance,servo system,wireless communication and etc. We have UL, CE,GS UKCA,KC,FCC INMETRO and other certificates for our products, Our professional QC&QA team can guarantee carry out ISO9001:2015 quanlity control system.

FAQQ1: What are the advantages of our company? A:Each product within compete safety certificates, a strong R&D team, the independent R&D and production of the main parts, and the produc quantity controlled from the source.Q2: Can you provide OEM and ODM services.A: Yes.Q3: What kind of certificates have you obtained for your products?
A:All the power inverters have obtained CE,KC,CB,RoHS and etc certification,which can meet the import requirements of most countries.Q4: How do you transport the goods?
A:Express, air shipment,sea shipment.Q5:How long can you offer the samples?
A:1~7days.
